PHAETON (40-QKH)

With the Tiffin Phaeton (40-QKH) model, you can visit the interior in 360° with detailed information about the interior features that users are curious about, color options, interior and exterior design visuals, information on general details.

Tiffin Motorhomes Phaeton Class A diesel motorhome 40 QKH highlights:

Rear Private Bedroom
Egress Window
Two Sofa Beds
Exterior TV
Convection Microwave
Bath and a Half

PHAETON (40-QKH) Specifications

Sleeps	8
Slides	5
Length	41 ft 4 in
Ext Width	8 ft 5 in
Ext Height	12 ft 7 in
Int Height	6 ft 11 in
Interior Color	Artist Taupe III, Coastal Sand III, Trend Beige III
Exterior Color	Gen 9, Gen 10; Euro Blue, Frosted Granite, Maroon Coral, Fire Opal, White Mahogany, Nasa
Hitch Weight	10000 lbs
Gross Weight	38320 lbs
Fresh Water Capacity	90 gals
Grey Water Capacity	66 gals
Black Water Capacity	50 gals
Tire Size	275/80R22.5
Generator	10.0kW Onan Manual Slide Out
Fuel Type	Diesel
Engine	Cummins L9
Chassis	Freightliner XCM
Horsepower	380 hp
Fuel Capacity	100 gals
Wheelbase	266 in
Available Beds	Queen
Torque	1150 ft-lb
Refrigerator Type	Stainless Steel Residential
Convection Cooking	Yes
Cooktop Burners	3
Number of Awnings	2
Axle Weight Front	14320 lbs
Axle Weight Rear	24000 lbs
LP Tank Capacity	35.7 gals
Water Heater Type	Truma Gas Continuous
Basement Storage	157 cu. ft.
TV Info	Front Overhead TV, LR TV, BR TV, Ext. TV
Awning Info	Girard Power Patio and Door
Washer/Dryer Available	Yes
Gross Combined Weight	48320 lbs
Shower Type	Radius
